Custom laser marking for own brand/OE customers upon request.
LP90 and LP01
Both models have an internal check valve which considerably reduces the response time on pick up. It also stops flow back for pumps installed below the collector pot. The LP01 pump has a AN6 male fitting as standard, but can also be supplied with a AN8 male or 1/4 BSP male thread.
A quick disconnect option is also available.
The LP90 has a M12x1.5mm female thread, AN6, AN8, Hose barb and QD fittings available.
The motor has been designed to provide the best performance with low amp draw.
At 0.2 bar (3psi) the pump only draws 2 amps yet flows more than 160 ltrs/hr.
Brushless 044:
A modern fuel pump for the new E85 type fuels which can be speed controlled via the ECU. Billet aluminium housing. Custom built motor and controller. 250 ltrs/hr @ 5 bar*, with less than 8 amp draw*. Weight 700g, 60x95mm. Available soon!!* Estimated
Digital fuel pump test bench:
A bench mounted fuel pump test machine, fully digital with data logger option. 5 channels displayed, flow, amp, volt, temp and pressure. Adjustable pressure and volts. Test or bed in ANY fuel pump. Set up fuel regulators, fuel systems. Supplied with flight case and is UKAS calibrated.
LP90 Pro Series Graph
Click on the graph above for more information
A bench mounted fuel pump test machine, fully digital with data logger option. 5 channels displayed, flow, amp, volt, temp and pressure. Adjustable pressure and volts. Test or bed in ANY fuel pump. Set up fuel regulators, fuel systems. Supplied with flight case and is UKAS calibrated.
