16407 – Electrical Connector, Deutsch DT06-3S, male, including terminals and securing clip

Product Code: 16407

Cost

£7.97

Specification

NameValue
Mating pin diameter1.5mm
Connector systemwire to wire
Number of positions3
Centre line (pitch)
SealableYes
Operating Voltage (VDC)250
Operating temperature range-55 to 125°C
Degree of protectionIP68
Pump
Wire
Wire Length
Weight
Length28
Width18
Height23

Description

Deutsch DT06-3S, male, including terminals and securing clip. This DT Series receptacle is designed for cable to cable connections, and when mated is sealed to a high degree of environmental protection. Safe, versatile and reliable, DT receptacle connectors are ideal for automotive applications.

Application Hints

Ensure electrical connections are all insulated properly.

Ensure all connections are tight.

Ensure terminals are the correct way round.
